Basic Info

Model No.: 86YD1022 ac linear actuator

Product Description

Product Code：

frame size 86mm / leads crew / the rated thrust 700lbs / driving force operates at 115VAC with a capacitor of 22.5uf / UL certified / rated thrust of 700lbs

Product Details:

Payment & Shipping Terms:

Features:
1、Our linear actuator will typically use the AC motor in frame size 86mm as a separate cylinder attached to the side of the actuator, either parallel or stuck out to the side, positioned perpendicular to the actuator.
2、In this construction, a solid driver shaft is geared to the drive ACME screw of the linear actuator so that the motor itself lies parallel with the actuator to better fulfill a linear motion control.
3、Compared with DC brush motor or stepper motor as the driving force in a linear actuator system, our single phase AC motor is used to actuate either commercial or industrial applications where high force and speed is critical.
4、The UL-certified motor operates at 115VAC with a rated power of 1/10HP.
Being accompanied by a speed ratio of 19.4:1, the AC linear actuator travels throughout a length of 152.4mm by having a rated thrust of 700lbs.


Applications:
They are suited to drive material handling equipment, modulate control valves and bottling and packaging machines.

Specifications:
